Working Principle:

• The hammers rotate at high speed (1500 – 3000 rpm) and impact the material fed into the center of the grinding chamber.
• The screen can be changed with mesh sizes starting from 0.8 mm, depending on coarse or fine grinding requirements.
• The automatic feeding unit ensures even distribution of raw materials across the full width of the grinding chamber.
• Operates smoothly and vibration-free, thanks to roller bearings.

Technical Features & Advantages:

• Grinding capacity: 5 – 60 tons/hour, depending on material type and configuration
• Adjustable rotor and screen configuration
• Grinding chamber equipped with temperature sensor to detect abnormal heat
• Bi-directional operation (reversible rotation) to extend hammer life
• Easy cleaning and replacement of screen and hammers
• Stable operation with low power consumption
• Suitable for aspiration grinding (with dust suction)
• Versatile applications: grinding, coarse grinding, fine grinding

Optional Features:

• Automatic dust filter cleaning system
• Dust extraction fan (with or without inverter control)
• Fine grinding protection screen unit
• Automatic feeder with speed adjustment
• Flexible discharge conveyor connection
