Technical Features & Key Advantages

• Fast mixing time: 30 – 120 seconds per batch
• Mixing volume: 200 – 12,000 liters (capacity: 1.5 – 120 tons/h)
• Mixing homogeneity: 1:100,000 – ideal for premix and precision formulas
• Integrated liquid spraying system: Up to 6% of batch volume – stainless steel spray bar with self-cleaning via compressed air
• Wear-resistant mixing paddles (Hardox): Easily replaceable and adjustable
• Optimized hygiene: No dead corners, large cleaning door, fully open discharge
• Fast discharge: Dual bomb doors, full bottom opening, pneumatic control – clean discharge in < 20 seconds
• Robust structure: Stable operation even at full load startup

Advanced Options

• Body made of stainless steel 304/316 or carbon steel S235
• Rilsan-coated shaft to prevent sticking
• ATEX22 certification – suitable for explosive dust environments
• Inverter control – soft start and better motor protection
• Integrated weighing frame
• De-aeration system from dosing hopper or overhead bin
• Optional multiple liquid spray bars with flat or round nozzles, adjustable upon request

Special Advantages

• High capacity, stable operation, low energy consumption
• Suitable for mixing dry and slightly moist ingredients without breaking particles
• Steel-to-steel bomb doors ensure tight seal even in case of pressure loss
• Rugged design, easy maintenance, long-term operation
